| Model | P-KG |
|---|---|
| Housingsize | 0072 |
| Elementsize | Size 10/3 |
| Elementtype | Double Open End with Flat Gasket |
| Connectiontype | G 3/4 |
| Flowrateliquid | 38 L/min (10 gpm) |
| Maximumoperatingpressure | 8 bar (116 psi) |
| Maximumoperatingtemperature | 50 °C (122 °F) |
| Minimumoperatingtemperature | -25 °C (-13 °F) |
| Filterhousingmaterial | Polypropylene |
| Housinggasketmaterial | Viton® |
| Length | 112 mm (4.41 inch) |
| Height | 315 mm (12.40 inch) |
| Width | 135 mm (5.31 inch) |
| Weight | 0.7 kg (1.54 lb) |
| Ped201468eu | Yes |
| Materialsaccordingtoec19352004 | Yes |
| Materialsaccordingtofdacfrtitle21 | Yes |
| Eac | Yes |
