| Outletdiameter | 177.8 mm (7.00 inch) |
|---|---|
| Inletdiameter | 203.2 mm (8.00 inch) |
| Bodydiametermaximum | 406.4 mm (16.00 inch) |
| Overalllength | 539.7 mm (21.25 inch) |
| Bodylength | 463.55 mm (18.25 inch) |
| Inletlength | 328 mm (12.91 inch) |
| Outletlength | 64 mm (2.52 inch) |
| Ratedflowlr | 38.5 m³/min (1360 cfm) |
| Ratedflowmr | 43.3 m³/min (1529 cfm) |
| Ratedflowhr | 46.4 m³/min (1639 cfm) |
| Restrictionlr | 14.91 mbar (5.98 inch H2O) |
| Restrictionmr | 19.91 mbar (7.99 inch H2O) |
| Restrictionhr | 24.91 mbar (10 inch H2O) |
| Family | EBB |
| Inletlocation | 224.5 mm (8.84 inch) |
