| Outletdiameter | 203 mm (7.99 inch) |
|---|---|
| Inletdiameter | 254 mm (10.00 inch) |
| Bodydiametermaximum | 457 mm (17.99 inch) |
| Overalllength | 735 mm (28.94 inch) |
| Length | 651 mm (25.63 inch) |
| Bodylength | 650 mm (25.59 inch) |
| Inletlength | 328 mm (12.91 inch) |
| Outletlength | 85 mm (3.35 inch) |
| Serviceclearance | 600 mm (23.62 inch) |
| Ratedflowlr | 75 m³/min (2649 cfm) |
| Ratedflowmr | 90 m³/min (3178 cfm) |
| Family | ERB |
| Inletlocation | 279 mm (10.98 inch) |
